Afikim Scooter FAQs

What are the weight capacities of Afikim Scooters?

• S4 – 500 lbs., Dual Seat – 600 lbs.
• S3 – 500 lbs.
• C4 – 400 lbs.
• C3 – 350 lbs.
• SE – 550 lbs.

What is the travel range of the Afikim Scooters?

• S4 – Up to 37 miles
• S3 – Up to 37 miles
• C3 – Up to 31 miles
• C4 – Up to 31 miles
• SE – Up to 28 miles

What seat size options are available for the Afikim Scooters?

• S4 – 18”, 20”, 22”, 24” and the 33” dual seat
• S3 – 18”, 20”, 22”, 24” and the 33” dual seat
• C4 – 18”, 20” and 22”
• C3 – 18” and 20”
• SE – 18” and 33” dual seat

What is the maximum speed of the Afikim Scooter?

All the Afikim Scooters have a maximum speed of 9.3 MPH, however with the upgrade option of the 18KPH motor the maximum speed is 12 MPH. This option is only available on the S model scooters.

Can canopies be added to any of the Afikim Scooters?

Canopies can be added to C4, S3 and S4 scooters. Dual canopies can be added to S3 and S4 if a dual seat has been added.

What type of tires are used on the Afikim Scooters?

All of the Afikim Scooters use pneumatic tires. Afikim chose this type of tire to add to the comfort of the ride. Much smoother ride with pneumatic tires.

Details:

• C Model: 3.5” wide by 12” high tire on both front and rear
• S3 Model: Front - 3” wide by 16” high, Rear - 3.5” wide by 17” high
• S4 Model: Front - 3.5” wide by 12” diameter, Rear - 3.5” wide by 17” diameter
• SE Model: Front - 2.75” wide by 15” high, Rear - 2.75” wide by 20” high

What types of motors are used on the Afikim Scooters?

Afikim uses a 950 watt motor on the C Model Scooter and a 1400 watt motor for the S and SE Model Scooters.

What are some other options that are available for Afikim Scooters?

Options include:

• Shabbat Kits can be installed on both C and S Models.
• Throttle orientation can be changed from right to left for left-handed users.
• Foot pedal addition available on the S Model for both throttle and foot pedal operation.

What type of suspension is built into the Afikim Scooter?

Both the C and S Models have independent suspension with shocks on all tires. The SE Model has heavy-duty suspension on the front tire only.

What type of lights are installed on the Afikim Scooters?

Afikim uses powerful long-lasting LED lights on all of its scooters.

What are some accessories that can be added to the Afikim Scooters?

Accessories available for addition:

• Seat Belts
• Cane/Crutch Holder
• Golf Bag Holder
• Rain Side (can be added if a canopy has already been installed)

Are there any storage compartments available on Afikim Scooters?

Storage options for C and S Models:

• Wire basket
• Rear lockbox
• Tote Container (S Model only)
• Front locking compartment

SE Model storage options:

• Rear basket
• SE dual - Rear cargo box

Warranty Information for the Afiscooter C 3-Wheel

LIFETIME

For the Lifetime of the Product from the date of delivery, Afikim Electric Vehicles will replace free of charge, any of the following Metal parts:

• Main Frame
• Seat Post
• Tiller Metal Parts

TWO-YEAR WARRANTY

For two (2) years from the date of delivery, Afikim Electric Vehicles will replace free of charge, any of the following parts:

• Power Unit (Motor, Transaxle & EMB)
• Controller
• Charger
• Harnesses
• Electronic sub-assemblies: Boards, Sensors, switches, Potentiometer, Fuses, Gas piston, Brakes

ONE-YEAR WARRANTY

For one (1) year from the date of delivery, Afikim Electric Vehicles will replace free of charge, any of the following parts:

• Bearings
• Bushings
• Shock absorbers
• Seat

WARRANTY EXCLUSIONS

This warranty does not extend to items which may require replacement due to normal wear and tear such as:

• Plastic shrouds
• Motor brushes
• Brake Pads
• Tires and tubes
• Bulbs & Lights
• Upholstery
• Rust, noises, and/or Circumstances beyond the control of Manufacturer
